Quyen Aluminium, based in Da Nang, Vietnam, is your go-to source for top-notch Aluminium 7075 Flat Bars. These bars are celebrated for their remarkable strength, impressive fatigue resistance, and solid machinability. Crafted with care under strict quality standards, they meet international specifications and cater to a variety of industries, including aerospace, defense, automotive, marine, and industrial engineering. Quyen Aluminium is committed to providing reliable solutions for structural, precision, and high-stress applications. With a strong emphasis on durability, consistency, and timely delivery, their Aluminium 7075 Flat Bars are trusted both locally and globally for high-performance, long-lasting use.
These flat bars are primarily made from an aluminium alloy that includes zinc (5.1%–6.1%), magnesium (2.1%–2.9%), and copper (1.2%–2.0%), along with small amounts of chromium and other elements. This high-strength blend gives them outstanding mechanical properties, such as superior tensile and yield strength, excellent fatigue resistance, and good toughness. While they may not be as corrosion-resistant as some other aluminium grades, they strike a great balance between strength and weight, making them perfect for demanding structural components.
Standards : ASTM B221, B211, B565, B316, AMS 4121 7075
Temper : T3,T4,T5, T6, T651 T6511
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total | ||||||||||
| Aluminium 7075 | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| – | 0.40 | – | 0.50 | 1.20 | 2.00 | – | 0.30 | 2.10 | 2.90 | 0.18 | 0.28 | 5.10 | 6.10 | – | 0.20 | – | 0.05 | – | 0.15 | |
| Standard | Temper | Tensile | Hardness | ||||
| Aluminium 7075 | Ultimate | Yield | Elongation | Brinell | |||
| T6, T651, T6511 | KSI | MPA | KSI | MPA | % | ||
| 83 | 572 | 73 | 503 | 11 | 150 | ||
| 73 | 503 | 63 | 434 | 13 | N/A | ||
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| EN AW-7075 | AlZnMgCu1.5 | A97075 | 3.4365 |
Aluminium 7075 Flat Bars find their place in industries that need strong, lightweight, and fatigue-resistant materials. In aerospace, they’re used for aircraft fittings, wings, and fuselage components. The automotive and motorsport sectors rely on them for performance parts, chassis, and structural assemblies. In defense, they’re essential for weapon components and armored equipment. Marine and industrial applications include high-load structures, precision tooling, and mechanical assemblies. Their unique combination of strength, fatigue resistance, and workability makes Aluminium 7075 Flat Bars a top choice for critical engineering and structural needs.
Yes, we offer custom sizes for Aluminium 7075 Flat Bars to meet specific project needs. Our team at Quyen Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@quyenaluminium.com
Aluminium 7075 Flat Bars are widely used in aerospace, military and high performance applications due to their unique strength to weight ratio and high fatigue resistance They are commonly used in aircraft structures, fuselage, wings and components a the landing is done in. Composites are also used in marine applications such as boat hulls and other structural components in harsh environments. Also, 7075 Flat Barss are used in precision machinery, tools, and automotive industries for products requiring high strength and durability. Their corrosion resistance and ease of machining make them ideal for rugged applications in harsh environments.
