Quyen Aluminium, based in Da Nang, Vietnam, is a reliable manufacturer and supplier of top-notch Aluminium 5083 Flat Bars. These bars are celebrated for their remarkable corrosion resistance, impressive strength, and long-lasting durability. Crafted with cutting-edge technology and rigorous quality control, they meet international standards. Quyen Aluminium caters to various industries, including marine, automotive, aerospace, construction, and industrial engineering, providing dependable solutions for structural components, machinery parts, and precision-engineered applications. With a commitment to performance, consistency, and timely delivery, Aluminium 5083 Flat Bars are a popular choice in both local and global markets for high-performance, durable applications.
The composition of Aluminium 5083 Flat Bars includes aluminium alloyed with magnesium (4.0%–4.9%), manganese (0.4%–1.0%), along with trace elements like chromium, silicon, and iron. This blend guarantees outstanding resistance to seawater, salt spray, and harsh chemical environments, all while maintaining excellent tensile and fatigue strength. On the mechanical side, Aluminium 5083 boasts superior weldability, machinability, and formability, making it ideal for demanding structural, marine, and industrial uses.
Standards : ASTM B221, B211, B565, B316, AMS 4121 5083
Temper : H111/H116/O
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 5083 | 0.4 | 0.4 | 4.0-4.9 | 0.4-1.0 | 0.1 | 0.25 | 0.15 | Bal |
|---|
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| AW-AlMg4,5Mn0,7 | Al-Mg-5 | A95083 | 3.3547 |
These flat bars find extensive applications in industries that require strong, lightweight, and corrosion-resistant materials. In the marine sector, they are used for shipbuilding, offshore platforms, and deck structures. The automotive industry employs them for chassis components, body panels, and mechanical assemblies. In aerospace, they serve as brackets, lightweight support structures, and interior frameworks. Construction projects utilize them for bridge supports, building frameworks, and architectural reinforcements. Industrial engineering relies on them for machinery frames, equipment components, and heavy-duty fabrication. The combination of these properties makes Aluminium 5083 Flat Bars a go-to choice across various sectors.
Yes, we offer custom sizes for Aluminium 5083 Flat Bars to meet specific project needs. Our team at Quyen Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@quyenaluminium.com
Aluminum 5083 flat bars are widely used in applications requiring good corrosion resistance, lightweight construction and good mechanical properties. They are important in marine applications, such as shipbuilding and offshore structures, because they can withstand high levels of salt water In the transportation industry, these thin films are used for car bodies, passenger vehicles people and rail cars. In addition to their use in chemical storage tanks and pressure vessels, their weldability and machinability make them ideal for building systems, bridges and industrial equipment applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
