Quyen Aluminium, based in Da Nang, Vietnam, is a reputable manufacturer and supplier of top-notch Aluminium 5754 Angles. These angles are celebrated for their impressive corrosion resistance, medium-to-high strength, and exceptional workability. Crafted with cutting-edge manufacturing techniques and rigorous quality control, they meet international standards. Quyen Aluminium caters to various industries, including marine, automotive, aerospace, construction, and industrial engineering, delivering dependable solutions for structural frameworks, reinforcements, and load-bearing applications. With a strong commitment to durability, precision, and timely delivery, Aluminium 5754 Angles are a popular choice in both domestic and international markets for high-performance, long-lasting uses.
The composition of Aluminium 5754 Angles primarily includes aluminium alloyed with magnesium (2.6%–3.6%) along with small amounts of manganese, chromium, and iron. This blend ensures excellent corrosion resistance, especially in marine and chemically aggressive settings, while also providing good tensile strength and fatigue resistance. On the mechanical side, Aluminium 5754 boasts outstanding weldability, machinability, and formability, making it perfect for structural and architectural components in demanding environments.
Standards : ASTM B221 / B211 ASME SB221 / SB211, EN573, EN485, AMS 4003, AMS 4102
Temper : O,H12,H14,H16,H18,H19,H22,H24
Standard : ASTM, ASME, AMS, GB/T, JIS
Thickness : 50 mm to 6000 mm Long
Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Length : 1 To 6 Meters, Custom Cut Length
Finish : Mill, Customer specific finish
Surface : Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
These Aluminium 5754 Angles find extensive application in industries that require strong, lightweight, and corrosion-resistant structural materials. In the marine sector, they are utilized for shipbuilding, deck frameworks, and offshore platforms. The automotive industry employs them for chassis reinforcements, body structures, and lightweight assemblies. In aerospace, they are used for interior support structures and brackets. Construction projects leverage them for bridges, building frameworks, roofing supports, and architectural designs. Industrial engineering also counts on them for machinery frames, racks, and heavy-duty fabrication. The unique combination of corrosion resistance, strength, and lightweight properties makes Aluminium 5754 Angles a go-to choice across various applications.
Yes, we offer custom sizes for Aluminium 5754 Angles to meet specific project needs. Our team at Quyen Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@quyenaluminium.com
Aluminum 5754 angles are widely used in applications where corrosion resistance, strength and lightness are required. The most common application is marine environments for boats and ships, as the compound is resistant to salt water. Because of its resistance to corrosion and weld resistance, it is also used in the manufacture of tanks, pressure vessels and pipelines, especially for the chemical and food processing industry in addition to angle 5754 in automobiles, building materials and construction in the structure of the. The durability of the alloy, combined with its ease of forming and welding, makes it ideal for these applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
